XENA-III > Blister packaging machine

​Semi-Automatic Blister Packing Machine

​

​- Compact in size.

- All parts in stainless steel or anodized aluminum.

- Fast and easy replacement of change size parts.

- Highly efficient operations to produce long run quality blisters.

- The XENA-III is fed with pre-cut PVC and ALU foils.

- Instrumented heating temperatures, forming and sealing pressures and counter.

- Electrical and pneumatic equipment.​

- Max forming depth : PVC/ALU-15mm

                                   ALU/ALU-10mm

- Blister Sizes : 136 x 100mm

                         [Blister per cycle:2]

- Temperature : 20 ~ 200 ℃

- Compressed Air : 3 ~ 9 bar​

- Dimension : 1,350(H) x 600(W) x 650(D)mm

- Power : AC 220V, 1Ph, 50/60Hz, 2Kw.

- Weight : 200kg

- Materials : PVC/ALU, PVC-PLDC/ALU

                    PETG/ALU, PVC/CRAFT PAPER

                    PVC-ACLAR/ALU. ALU/ALU​
